| Item NO.: | SR(440-460)-144M-DGB6-H |
| Product Origin: | China |
| Color: | Black, silver, full black |
| Lead Time: | 7-10 days |
| Order(MOQ): | 31 pcs per pallet |
| Dimension: | 2094*1038*35mm |
| Warranty: | 30 Years Warranty |
| Certificate: | TUV, CE, ISO, ETL, CQC |
Sunry bifacial technology enables additional energy harvesting from rear side, increasing total efficiency of whole module up to 30%.
Sunry solar photovoltaic modules are designed for large electrical power requirements. With 30 years warranty, PERC offers high power, reliable performance for both on-grid, off-grid and hybrid grid solar projects.

| Electrical Characteristics At Standard Test Conditions (STC) | ||||||
| Module | SR(440-460)-144M-DGB6-H | |||||
| Encapsulation | Glass/EVA/Cell/EVA/Glass/Backsheet | |||||
| Max. Power (W) | 440 | 445 | 450 | 455 | 460 | |
| Max. Power Voltage (Vmp/V) | 41.4 | 41.6 | 41.8 | 42 | 42.2 | |
| Max. Power Current (Imp/A) | 10.63 | 10.7 | 10.77 | 10.84 | 10.9 | |
| Open Circuit Voltage (Voc/V) | 49.7 | 49.9 | 50.1 | 50.3 | 50.6 | |
| Short Circuit Current (Isc/A) | 11.27 | 11.34 | 11.41 | 11.48 | 11.56 | |
| Module Efficiency (%) | 20.24 | 20.47 | 20.7 | 20.93 | 21.2 | |
| Power Tolerance (W) | 0~+5W | |||||
| Temperature Coefficient of Isc | 0.033%/°C | |||||
| Temperature Coefficient of Voc | -0.26%/°C | |||||
| Temperature Coefficient of Pmax | -0.34%/°C | |||||
| STC | Irradiance 100w/m2, Cell Temperature 25℃, Air Mass 1.5 | |||||
| Product Weight: | 27kg | Packing: | 31pcs/pallet, 726pcs/40HQ |
| Pallet dimension: | 2120*1100*1180mm | Pallet weight: | 860kg |



Advantages of Sunry 30KW Off Grid Solar Energy System Commercial Use 30Kwp 400V 3-Phase Solar Power System
Welcome to contact us for the assistance of an expert to start your own solar projects!
